Our power distributors allow you to connect multiple devices flexibly and ensure an even distribution of electrical load. This helps prevent overloads and short circuits, ensuring your exhibition stand is not only functional but also safe and visually appealing.
Choose the right distributor and ensure flexibility and safety at your stand!
Power up to (in kW)
The power distributors at your stand have a very important function and must not be missing. They ensure an even distribution of electricity and reliably protect your devices and machines from overload. This makes a significant contribution to the safety of your stand.
Our power distributors are available for rent. Installation and dismantling are included in the price. Please note that the power distributor can only be mounted to the already ordered, suitable electrical connection.
To help you quickly and easily understand the technical specifications of each distributor, we have created a clear summary for you.
Distributor type 1 for one main connection up to 9 kW
Technical features:
- Two RCDs
- Four Schuko sockets
- One CEE socket outlet 16 A, 5-pin
Distributor type 2 for one main connection up to 20 kW
Technical features:
- One RCD and automatic circuit breakers
- Six Schuko sockets
- Two CEE sockets 16 A, 5-pole above a 3-pole 16 A circuit breaker
Distributor type 3 for one main connection up to 40 kW
Technical features:
- One automatic circuit breaker
- Fourteen Schuko sockets
- Two CEE sockets 16 A, 5-pin
Distributor type 4 for one main connection up to 40 kW
Technical features:
- Four fuse elements
- Four CEE sockets 32 A, 5-pin
Distributor type 5 for one main connection up to 83 kW
- Fuse elements
- Six 32 A CEE sockets
- Two 63 A CEE sockets
Installation:
We strive to carry out the installations in a way that is unobtrusive for exhibitors and visitors. Installations from the supply shaft to the connection point are carried out exclusively via the hall floor. Therefore, a raised floor is advantageous.
Sketch/Plan:
To ensure that the connection points meet your requirements, we need a stand sketch showing the lines, stand grounding, and connections. You can upload this after your order or at a later date, but no later than 21 days before the exhibition.
Power Distributor:
To ensure adequate energy distribution, you need a suitable power distributor for a power connection of 9 kW or more. You can only do without this if it is a pure machine connection without user-operable sockets. For a power connection of 9 to 20 kW, a power distributor is included in the price. For all other connections from 20 kW, the power distributor must be ordered separately.
Stand Grounding:
For metal stands, stand grounding is essential. Please order the stand grounding separately.
